ONLY FOR CERTIFIED TECHNICIANS DISCLAIMER: NO RETURNS ALLOWED IF THE BAG OR BOX IS OPENED (Watermark in each item)
Buyer pays return shipping ($4.95 to $12.00 1st Class), 8-10 days refund time Approx. Every item will be tested in factory lab.
IMPORTANT: Your old part number is no longer available, we ship new part #, perfect fit old and new serials, If you need help send picture of the old part #
IMPORTANT: You receive FREE pad dispenser optional USE for serial K890
You can try use in your old model if you need it
Perfect Fit for old models
NOTE: The Program Code is located on the Model/Serial Plate on this unit after the word Code.
1. Press and hold the Door Alarm Keypad.
2. Press and hold Freezer Temperature DOWN /- Keypad within 3 seconds.
3. Release the Door Alarm Keypad and wait 3 seconds.
4. The control will display PE to indicate the programming mode.
5. Entry is confirmed by pressing the Freezer Temperature DOWN /- Keypad once more.
6. The control will display the current Program CODE. This value should be validated with the Program CODE printed on the unit serial plate.
NOTE: If the Program CODE is correct, the Programming Mode is exited by pressing the Door Alarm Keypad for 3 seconds.
7. Press the Refrigerator Temperature UP /+ Keypad or Refrigerator Temperature DOWN /- Keypad to change the digit value with each key press.
8. The decimal point indicates the selected digit. Press the Freezer Temperature UP /+ Keypad to select the next digit.
9. Once the desired Program CODE is entered, press and hold the Freezer Temperature DOWN /- Keypad until the Program CODE begins flashing indicating it has been saved.
NOTE: If you attempt to enter an invalid Program CODE the control will not save the new code, but will beep. (The unit will NOT run with a Program CODE of 0000).
Once the Program CODE has been saved the Programming Mode is exited by pressing any key. If the new code is incorrect this process should be repeated. The Programming mode can be exited at any time by pressing the Door Alarm key for 3 seconds or will exit if unattended for four minutes.
ww.appliance-repair-manuals.org
see pictures, manuals and videos - DOC45690
TEXTING PICTURE WE CAN HELP - ADD ORDER NUMBER AND:
1-ORIGINAL PROBLEM 2-PROBLEM AFTER CHANGE THE NEW ITEM
