IMPORTANT:
- NEW PART NUMBER your old part number is no longer available, new part number fits old and new serials.
- The product could be a different color or shape, (internal item, color does not interfere with operation)
- If you don't fix the original problem, the new item will be broken again. TERMINAL CONNECTORS or bad electric contact need fix it, cleaning and close terminal to better power contact.
TECHNICAL NOTE
- Control board are often misdiagnosed. or wrong diagnostic or online fake videoif you don't fix the original problem, the new item will be broken again.
- Disconnect the power source to your dryer before you conduct this or any other repair. Either unplug the unit from the wall outlet, remove the appropriate fuse from the fuse box, or flip the appropriate breaker in the circuit breaker panel.
- When you finish the repair it, we recommend that you take a peek behind the dryer before fully pushing it back. It is a common mistake to push back the dryer too far which crushes the dryer vent. If you crush the vent, it will restrict air flow, and will reduce performance of the dryer — and may lead to a lint clog blocking the vent.
owner PartSelect all right reserved - video just educational propose
BEFORE TO USE THE NEW PART:
1-Change your old fuse, included free in Package.
VIDEO Replacing a Dryer Thermal Fuse
owner .appliance-parts-experts.com all right reserved - video just educational propose
2-Double check external and internal dyer ducts (OBSTRUCTIONS, the part will be broken again ).
3-Double check board or timer electric terminal contacts, It is important to remember that vibrations in appliances generate bad electrical connections in your terminals, switch cables and connectors. Please remember to check that all your connections are correct before installing a new part.
If Dryer does not work?
Very important !!!!
80% is the Control Board
10% is door lock switch
5% is bad Electrical terminal contact in motor, board or switch
5% motor sensor or board
VIDEO SAMPLE DRYER BOARD - CLICK HERE
OLD PART NUMBERS
NO interchangeable in serials or models
NO interchangeable in serials or models
SERIAL 35 Fits old numbers REV. A B C D E F G H I , CKD11616X, AP6015083 , WPW10111616, W10111616, 1447617, 3978982, PS11748355, W10067040, W10074270, W10111607, W10111609, W10111614, W10111616R, W10118243, W10118243R.
SERIAL 37 old numbers REV. A B C D E F G H I ,AP6015082 , WPW10111606,,W10111606, 3978981, 3978994, PS11748354, W10050520, W10111606R.
5 connector
SERIAL 38 old numbers CKD74746X REV. A B C D E F G H I ,AWPW10174746, AP6016287,W10174746, PS11749573, W10177388, W10182365, W10182365R
SERIAL 39 old numbers REV. A B C D E F G H I , CKD41671X , WPW10141671 (AP6015706) replaces W10141671, 1451295, PS11748987, W10119241, W10141671R
SERIAL 40 old numbers REV. A B C D E F G H I , CKD10641X , WPW10110641,AP6015062, W10110641, PS11748333, W10110641R.
SERIAL 41 old numbers REV. A B C D E F G H I CKD11617X, WPW10111617,AP6015084, W10111617, 3978983, PS11748356, W10067050, W10074280, W10111608, W10111610, W10111617R, W10118244, W10118244R
SERIAL 42 old numbers REV. A B C D E F G H I CKD56719X, WPW10256719,AP6017976,
W10256719, PS11751277.
SERIAL 43 old numbers REV. A B C D E F G H I CKD74745X, WPW10174745, AP6016286,W10174745, PS11749572, W10174745R, W10182366, W10200473.
